Machines d’exploration Sandvik
SANDVIK vous propose une large gamme d’appareils de forage d’exploration, pour des applications souterraines et de surface. On distingue 3 séries : les sondeuses carotteuse légères DE100, les plates-formes de carottages lourdes DE700 et les plates-formes de carottages lourdes multifonctions pour carottage et circulation inverse DE800.
| Models | Former name | Hole depth,m (ft) | Feeding force,kN (lbf) | Pulling force,kN (lbf) |
|---|---|---|---|---|
| DE110 | Onram 100 | 230 (755) A | 16.8 (3770) | 10.7 (2405) |
| DE130 | Onram 1000/3 | 1064 (3490) B | 46.1 (10350) | 61.5 (13820) |
| DE140 | Onram 1500 | 1592 (5223) B | 92.2 (20727) | 92.2 (20727) |
| DE150 | 1945 (6381) N | 147 (33000) | 147 (33000) |
| Models | Former name | Drilling method | Hole depth, m (ft) | Feeding forcekN (lbf) | Pulling forcekN (lbf) |
|---|---|---|---|---|---|
| DE710 | UDR200DLS | Diamond Core | 1126 (3693) N | 53.2 (12000) | 91.2 (20500) |
| DE740 | UDR250D | Diamond Core | 1837 (6025) | 67 (15050) | 133.5 (32000) |
| Models | Former name | Drilling method | Hole depthm (ft) | Feeding forcekN (lbf) | Pulling forcekN (lbf) |
|---|---|---|---|---|---|
| DE810 | UDR650 | Multipurpose* | 954 (3129) N | 45 (10000) | 75 (16800) |
| DE840 | UDR1200 | Multipurpose* | 2223 (7291) N | 113 (25350) | 226 (50700) |
| DE880 | UDR1200HC | Multipurpose* | 3174 (10411) N | 113 (25350) | 226 (50700) |
